凿岩速度 Drilling speed
|
0.5～1m/min
|
发动机功率 Engine power
|
45kw
|
|
冲击能量 Striking energy
|
≧85J
|
额定油泵流量 Rated pump flow
|
125l/min
|
|
钻孔深度（一次推进） Each drilling depth
|
≦2000mm
|
系统工作压力 System working pressure
|
16Mpa/12Mpa
|
|
钻孔直径 Drilling diameter
|
36～45mm
|
空压机气量 Compressor capacity
|
1m3/min/1.4 m3/min
|
|
垂直钻孔范围 Vertical drilling scope
|
最远 Farthest
|
4000mm
|
空压机气压 Compressor pressure
|
≧0.8Mpa
|
|
最近 Nearest
|
1000mm
|
台车运输尺寸 Transportation size
|
4200×2100×2570mm
|
|
最高 Highest
|
1800mm
|
冲击频率 Impact frequency
|
≧46HZ
|
|
水平钻孔范围 Horizontal drilling scope
|
最高 Highest
|
3800mm
|
行走速度 Working speed
|
3km/h
|
|
最低 Lowest
|
300mm
|
爬坡能力 Grade ability
|
22°
|
|
钻臂摆角 Swing angle of drill boom
|
±30°
|
台车净量 Net weight
|
4.2T
|
|
推进导轨摆角 Swing angle of propel guide rail
|
±20°
|
补偿行程 Compensative travel
|
560mm
|
